MAAG – Elastomer Extrusion Pumps
When it comes to manufacturing profiles and dealing with strainers, high requirements are placed on pumping consistency and extrusion lines. The new gear pump series extrex⁶ RV/RB from MAAG raises the performance of gear pumps for elastomer extrusion to new levels in terms of both economy and processing technology. Product quality is guaranteed by a stable discharge, the lowest tolerance deviations and achieving process stability in quick time.
The recently developed series is characterized by the optimized conveying characteristics for gear pumps. This series expands the processing scope for temperature, degree of plasticizing and pressure build-up when working the compounds. It simplifies the operating mode of the extrusion line and dramatically improves the quality of the end product. extrex® gear pumps have optimized flow channel geometry and a temperature-controlled pump housing.
Technical Specifications
| Differential pressure (bar) | max. 120 |
| Viscosity (MPas) | Up to 30000000 |
|---|---|
| Temperature (°C) | Up to 130 |
| Throughput rate (kg/h) | extrex⁶ RV: 15 – 1500 extrex⁶ RB: 50 – 1000 |
| Pump size | extrex⁶ RV: 36 – 110 extrex⁶ RB: 56 – 110 |
| Housing | Alloy steel |
| Gear shafts | Nitrided tool steel, prepared for shaft cooling |
| Bearing | Tool steel |
| Shaft seal | Alloy steel |
| Pump heating | Liquid temperature controlled |
Key Features
- Optimized flow channels
- Highly efficient self-cleaning properties
- Low pulsation pumping even at high differential pressures
- Compact design
- Gentle pressure increases
- Minimal temperature increase
- Leak-free operation depending on compound sensitivity possible
